Diagonal Size

15.6" (39.5cm)

Resolution

1920 x 1080 (Ful HD, 2 Mp)

Aspect Ratio

16:9

Panel Brightness

450 cd/m²

Viewing Brightness

385 cd/m²

Response Time

5ms

Viewing Angle

Horizontal / Vertical: 178^o/ 178^o

Right / Left: 89^o / 89^o

Up / Down : 89^o / 89^o

Viewable Area

344.2 x 193.6mm (13.6" x 7.6")

Pixel Pitch

0.179mm

Vesa Mounting

100mm x 100mm

Touch Points

10 (HID, with supported OS)

Touch Method

Finger

Glove (Latex)

Stylus

Interfaces

1 x HDMI

1 x Display Port

2 x USB 3.2 Gen 1 Type-A (USB Hub)

1 x USB Type-B (Touch Interface)

2 x 2W Speaker

Dimensions

389mm x 246.5 x 45.5mm

Weight

2kg

Boxed Dimensions

475mm x 343mm x 169mm

Boxed Weight

3.9kg

EAN Code

4948570122530

Colour

Black

External PSU

Input: 100 - 240Vac, 50-60Hz

Output: 12Vdc, 3.75A

Power Usage

12W typical Operation

8W stand by

0.5W off mode

Operating

Temperature: 0 to 40^oC / 32 to 104^oF

Humidity: 20 to 80% (Non Condensing)

Storage

Temperature: -20 to 60^oC / 32 to 104^oF

Humidity: 10 to 90% (Non Condensing)

CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA

Energy efficiency class (Regulation (EU) 2017/1369) C
