Symbology Decode Capability

UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes, securPharm, DotCode, Dotted DataMatrix

OCR-A, OCR-B, MICR, US currency

Minimum Element Resolution

Code 39: 3 mil; Code 128: 3 mil; Data Matrix: 5 mil; QR Code: 5 mil

Interface

RS232 9-pin male D-sub

Light Source

660 nm Hyper Red LED

Aiming pattern: circular 617 nm amber LED

Swipe Speed

Up to 120 in./305 cm. per second for 13 mil UPC in optimized mode

Field Of View

52° H x 33° V nominal

User Indicators

Good decode LEDs, rear view LEDs, beeper (Adjustable tone and volume)

145mm x 86mm x 83mm (5.7in x 3.4in x 3.3in)

Weight

318.0 g (11.2oz)

Colour

Black

Input

4.5 to 5.5 VDC host powered

4.5 to 5.5 VDC external power supply

Operating Current (Presentation Mode): 335 mA

Operating Current (Trigger Mode): 335 mA

Standby Current (Presentation Mode): 135 mA

Standby Current (Trigger Mode): 75 mA

0° to 50° C (32° to 122° F)

5% to 95% RH, non-condensing

Storage

-40° to 70° C (-40° to 158° F )

85% RH, non-condensing at 70°C

Sealing

IP52

IEC 62368-1 2nd ed.

EN 62368-1:2014/AC:2015

UL/IEC 60950-1, 2nd ed.

CAN/CSA C22.2 No.60950-1, 2nd ed.

LED Safety

IEC 62471:2006 (Ed.1.0)

EN 62471:2008 (LED)

EMI/RFI

FCC 47 CFR Part 15B, ICES-003, EN55032, EN55024, EN55035, VCCI, and SABS

Environmental

EN 50581:2012

RoHS 2011/65/EU (2015/863) - EN 50581:2012, IEC 63000

REACH 1907/2006
