Symbology Decode Capability

UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN Format, UCC Coupon Extended Code, ISSN EAN Code 128 Including GS1-128, ISBT 128, ISBT Concatenation, Code 39 including Trioptic Code 39, Convert Code 39 to Code 32 (Italian Pharmacy Code), Code 39 Full ASCII Conversion Code 93 Code 11 Matrix 2 of 5 Interleaved 2 of 5 (ITF) Discrete 2 of 5 (DTF) Codabar (NW - 7) MSI Chinese 2 of 5 IATA Inverse 1D (except all GS1 DataBars) GS1 DataBar including GS1 DataBar-14, GS1 DataBar Limited, GS1 DataBar Expanded

Interface

RS232 9-pin male D-sub

Light Source

650 nm Laser Diode Class 2

Scan Pattern

Single line

Scan Speed

100 scans per second

Scan Angle

35°

User Indicators

Direct decode indicator, good decode LEDs, beeper (adjustable tone/volume)

Dimensions

152mm x 64mm x 85mm (6.0in x 2.5in x 3.3in)

Weight

150.0 g (5.3oz)

Colour

Black

Input

4.5 to 5.5 VDC host powered

4.5 to 5.5 VDC external power supply

Operating Current: 175 mA (typical)

Standby Current: 90 mA (typical)

0° to 50° C (32° to 122° F)

5% to 95% RH, non-condensing

Storage

-40° to 70° C (-40° to 158° F )

85% RH, non-condensing at 70°C

Sealing

IP30

EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011; IEC 60950-1: 2005

+ A1: 2009; UL 60950-1, second edition; CAN/CSA-C22.2 No. 60950-1-07

Laser Classification

CDRH Class II; IEC Class 2

EMI/RFI

FCC 47 CFR Part 15, Subpart B, Class B; ICES-003 Issue 4, Class B; Compliant with EMC Directive 2004/108/EC

Environmental

Compliant with RoHS Directive 2011/65/EU; EN 50581: 2012
